derul High Flexible Shielded Servo Cable SF Industrial Series Factory

derul High Flexible Shielded Servo Cable SF Industrial Series

Especificación

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Pregunte ahora Siguiente Producto

INTRODUCCIÓN

China's derul high-flexible shielded servo cable manufacturer, focusing on the field of high-flexible cables, factory direct sales, quality assurance.

Application scope of derul high flexible shielded servo cable:

Used where frequent, continuous repetitive movements are required, and also where there is moderate mechanical stress with free movement.

Highly flexible servo double-shielded cable integrates control and power connections and serves as the connecting cable between the inverter, servo controller and motor.

The special shielded cable for servo motor can effectively eliminate and reduce the interference caused by surrounding cables.

Highly flexible servo shielded cables are used in drag chains and moving mechanical parts. When used together with drag chains, the effect is better.

derul highly flexible shielded servo cable structure:

Conductor: Fine oxygen-free bare copper wire, multi-stranded soft conductor, in line with GB/T3956 (VDE0295/IEC60228) 60228 Class5 or 6 standard

Insulation: High-strength modified PVC or PE and other materials with excellent electrical insulation properties, color-coded, no duplication (can be customized and produced according to customer requirements)

Cabling: short-pitch layer stranding, composite cabling structure for 12 cores and above

Twisted pairs: Twisted pairs of insulated wires are twisted into cables at a reasonable pitch.

Shielding: Aluminum foil shielding (optional) plus copper mesh braided shielding, braiding density ≥85% (shielding can be customized and produced according to customer requirements)

Outer sheath: high strength and low viscosity special PVC composite material;

Sheath color: gray (default), black, orange, green (other colors can be customized according to customer requirements)

derul high flexible shielded servo cable technical parameters:

Rated voltage: data cable: 300V; power cable: 300/500V, 0.6/1KV

Test voltage: data cable: 1500V; power cable 1500V, 3500V

Insulation resistance ≥20MΩ/km (20°C)

Minimum bending radius: mobile use: 7.5X cable outer diameter, fixed installation: 4X cable outer diameter

Operating temperature range: mobile use: -5℃~70℃, fixed installation: -20℃~80℃

VENTAJAS

The special shielded cable for derul servo motor can effectively eliminate and reduce the interference caused by surrounding cables.

Derul highly flexible servo shielded cables are used in drag chains and moving mechanical parts. When used together with drag chains, the effect is better.

CAPACIDAD DE PERSONALIZACIÓN

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

Preguntas más frecuentes

Q: ¿Derul Cable es un fabricante o una empresa comercial?

A: Derul Cable es un fabricante de cables especiales con sede en Shanghai.

Q: ¿El precio es negociable?

A: Sí, el precio es negociable de acuerdo con la cantidad de compra.

Q: ¿Cuál es el MOQ regular para el cable?

A: Cualquier cantidad está bien para comprar para el producto en stock. Para el producto que debe fabricarse después del pedido, el MOQ suele ser de 100 a 200 m por tipo.

Q: ¿Cómo puedo obtener muestras?

A: Después del pago del costo potencial, incluido el flete expreso y la confirmación de la dimensión y estructura del cable, organizaremos la muestra y la enviaremos directamente a su puerta.

Q: ¿Está disponible el servicio OEM o ODM?

A: Los servicios de OEM y ODM están disponibles. Puede proporcionarnos su requisito y lo evaluaremos para avanzar.

Q: ¿Cuál es el tiempo de producción regular?

A: Para una cantidad regular, generalmente requiere entre 15 y 25 días para producirse.
