YFFB flat cable for traveling and port machinery| Flat cable supplier-Shanghai DerulCable Price

YFFB flat cable for traveling and port machinery| Flat cable supplier-Shanghai Derul Cable

Especificación

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Pregunte ahora Siguiente Producto

INTRODUCCIÓN

Derul YFFBG crane flat cable|Application scope:

Power transmission and control cables are widely used in mobile equipment such as cranes, trolleys, and transmission machinery. Such as metallurgy, electric power, ships, logistics transportation systems, and port machinery.

Derul YFFBG crane flat cable | Structure:

Conductor: Multi-stranded flexible oxygen-free copper wire conforms to DIN VDE 0295 level 5

Insulation: High-quality oil-resistant, flame-retardant PVC blend Color: Colored or coded cores with grounded yellow and green cores

Sheath: Premium oil-resistant, flame-retardant PVC blend Color: Black or gray

Derul YFFBG crane flat cable | Electrical characteristics:

Rated voltage: U0/U 300/500 V

Test voltage: U 2500V

Temperature range: ℃Mobile installation: -15℃～+70℃

Fixed installation: -30℃～+70℃

VENTAJAS

This product is cold-resistant, soft, wear-resistant, and oil-proof.

The bending radius is smaller than that of round cables, saving installation space.

Multiple cables can be overlapped and bundled.

When the core wires are arranged in a single row and in a straight line: the hanging length is >40m and the moving speed is >2m/s. It is recommended to add load-bearing steel wire or spun yarn.

When the core wires are arranged in plum blossom type twisting: hanging length > 80m and moving speed > 4-10m/s, it is recommended to add load-bearing steel wires.

CAPACIDAD DE PERSONALIZACIÓN

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

Preguntas más frecuentes

Q: ¿Derul Cable es un fabricante o una empresa comercial?

A: Derul Cable es un fabricante de cables especiales con sede en Shanghai.

Q: ¿El precio es negociable?

A: Sí, el precio es negociable de acuerdo con la cantidad de compra.

Q: ¿Cuál es el MOQ regular para el cable?

A: Cualquier cantidad está bien para comprar para el producto en stock. Para el producto que debe fabricarse después del pedido, el MOQ suele ser de 100 a 200 m por tipo.

Q: ¿Cómo puedo obtener muestras?

A: Después del pago del costo potencial, incluido el flete expreso y la confirmación de la dimensión y estructura del cable, organizaremos la muestra y la enviaremos directamente a su puerta.

Q: ¿Está disponible el servicio OEM o ODM?

A: Los servicios de OEM y ODM están disponibles. Puede proporcionarnos su requisito y lo evaluaremos para avanzar.

Q: ¿Cuál es el tiempo de producción regular?

A: Para una cantidad regular, generalmente requiere entre 15 y 25 días para producirse.
