Supply flexible low smoke halogen-free cable | China Derul brand manufacturer Company

Supply flexible low smoke halogen-free cable | China Derul brand manufacturer

Especificación

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Pregunte ahora

INTRODUCCIÓN

China Derul brand low smoke halogen-free cable:

It is suitable for electrical connections in industrial automation, mechanical and electrical equipment, machine tools and other mechanical equipment, logistics transmission systems, production lines and other control systems. It is especially suitable for fixed installation in dry or humid indoor environments in industrial environments. It can also be used for non-continuous reciprocating motion without Mobile installation with forced traction. The cable has good flexibility. The sheath is made of low-smoke halogen-free materials and is suitable for crowded places with environmental protection requirements, such as airports, train stations, commercial buildings, hospitals and other public places. Low smoke after burning, higher flame retardant level, safer.

China Derul brand product structure：

Conductor: Multiple strands of finely twisted bare copper wire, conforming to IEC 60228/VDE 0295, Category 5 conductor

Insulation: Special halogen-free mixed environmentally friendly materials

Core wire: The core wire is twisted into a cable, and the color of the core wire conforms to VDE 0293

JZ black core wire, white digital code, with yellow and green wires

JB color core wire, with yellow and green wires

OZ black core wire with white digital code, without yellow and green wires

OB color core wire, without yellow and green wires

Outer sheath: Special halogen-free mixed environmentally friendly material

Outer sheath color: gray

VENTAJAS

Working voltage: 300/500V

Test voltage: 2000V

Insulation resistance: ≥20MΩ/km (20°C)

Small bending radius: mobile installation: approx. 15x D (cable outer diameter)

Fixed installation: approx. 4x D (cable outer diameter)

Operating temperature: mobile installation -5°C to +70°C

Fixed installation -30°C to +80°C

Flame retardant properties: Conforms to VDE 0472 – 804 Part B Class B test standards, and IEC 60332-1

CAPACIDAD DE PERSONALIZACIÓN

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

Preguntas más frecuentes

Q: ¿Derul Cable es un fabricante o una empresa comercial?

A: Derul Cable es un fabricante de cables especiales con sede en Shanghai.

Q: ¿El precio es negociable?

A: Sí, el precio es negociable de acuerdo con la cantidad de compra.

Q: ¿Cuál es el MOQ regular para el cable?

A: Cualquier cantidad está bien para comprar para el producto en stock. Para el producto que debe fabricarse después del pedido, el MOQ suele ser de 100 a 200 m por tipo.

Q: ¿Cómo puedo obtener muestras?

A: Después del pago del costo potencial, incluido el flete expreso y la confirmación de la dimensión y estructura del cable, organizaremos la muestra y la enviaremos directamente a su puerta.

Q: ¿Está disponible el servicio OEM o ODM?

A: Los servicios de OEM y ODM están disponibles. Puede proporcionarnos su requisito y lo evaluaremos para avanzar.

Q: ¿Cuál es el tiempo de producción regular?

A: Para una cantidad regular, generalmente requiere entre 15 y 25 días para producirse.
